Ny modell! - Bakkenett (FTA) og Kabeltuner.
- New CPU
- Support for new codec H.265 HEVC
- Simply installation
- FullHD resolution 1080p
- 1x DVB-T2/C tuner
- 1x Card Reader
- 1x HDMI port
- 1x SCART
- 1x RS232
- 1x USB 2.0
- 1x LAN RJ 45
- 1x S/PDIF optical digital audio output
- Chipset: ALI M3626
- Flash Memory: 8 MByte
- DDRIII Memory: 256 Mbyte
- Power max. 18W
- 7 segment Display
- 7-day electronic guide
- Time Shift recording and PVR function
- PIG ( Picture in Graphic )
- FTP manager, games, weather and many more…
- Automatic PAL / NTSC conversion
- 6000 TV / Radio Stations
- Support FAT32 and NTFS
- media player with support many formats
Tuner & Band Switching
| Type (front –end) |
DVB-T2/C Compliant (MPEG2/H.264/H.265) |
| Frequency Range |
(VHF)177.5MHz~226.5MHz (UHF)474MHz~866MHz |
| Connector |
Single head, IEC female head |
| Loop-Through |
No |
Demodulator
| Demodulation |
QPSK/16QAM/64QAM/256QAM |
| Terrestrial – DVB-T2 |
Support all DVB-T2 modes including multiple PLP (up to 255 PLPs) and MISO |
| Cable – DVB-C |
Automatic calculation of TS output rate based on ISSY and L1-signaling |
Video
| Video Decode |
ISO/IEC 13818-2 MPEG1, MPEG-2 MP@ML, H.264, H.265, VC1, DV, DivX and MPEG4 |
| Profile Level |
SD Formats: MPEG-2 MP@ML; MPEG-4 Part 10 MP@ Level 3.0 and HP@ Level 3.0 HD Formats: MPEG-2 MP@ML and MP@HL; MPEG-4 Part 10 MP@ Level 3.0/4.0 and HP@Level 3.0/4.0 |
| Video Format |
4:3, 16:9 Pan & Scan, Letterbox |
| Graphic |
2D Graphic |
| Video System |
PAL, NTSC, SECAM |
| Video Resolution |
480i,480p,576i,576p, 720P, 1080i, 1080P |
Audio
| Audio Decode |
MPEG-1/2 layer I and II (Musiccam), MPEG4 AAC and MPEG4 AAC-HE (AAC+), Dolby Digital (AC-3) with bit rates up to 640 Kbits/s, LPCM up to 48 KHz, MP3 |
| Sampling Frequency |
32, 44.1, 48KHz |
Chip & Memory
| CPU |
ALI3626 |
| Flash Memory |
8MByte SPI NOR Flash |
| SDRAM |
256MB DDR3 1866 |
A/V & Data In/Out
| Analog A/V |
CVBS, Audio L/R |
| S/PDIF |
Digital Audio Output |
| HDMI |
Digital Video and Audio output (HDMI 1.3a) |
| LAN |
1 X RJ45 |
| USB2.0 |
1 X USB Ports 2.0 Host |
Power Supply
| Input Voltage |
Power panel (12V/1.5A) |
| Power Consumption |
Max.18W |
Front Panel
| Display |
4 X 7 Segment Display for Time & Channel Number |
| 3 Navigation Keys |
Power, CH+\CH- |
Physical Specification
| Mechanical Type |
Plastic front panel + Metal Housing |
| Dimensions |
260mm |
| Operating Temperature |
0 ~ 50°C |
