Produktbeskrivelse
50 mm konusdiskanthøyttaler. På grunn av den lukkede baksiden kreves ingen ytterligere montering.
Generell informasjon
• Nominal power handling with high pass:60 W (12 dB/Okt.; 5000 Hz)
• Peak power handling with high pass:100 W (12 dB/Okt.; 5000 Hz)
• Nominal impedance Z:8 Ohm
• Frequency response:1000–30000 Hz
• Mean sound pressure level:91 dB (1 W/1 m)
• Opening angle (-6 dB):97°/8000 Hz
• Excursion limit:+/-0.5 mm
• Resonance frequency fs:1500 Hz
• Magnetic induction:0.8 T
• Magnetic flux:70 uWb
• Height of front pole-plate:2.5 mm
• Voice coil diameter:14 mm
• Height of winding:2.5 mm
• Cutout diameter:56 mm
• Net weight:0.14 kg
• D.C. resistance Rdc:6,5 Ohm
• Effective piston area Sd:17 cm²
• Inductance of the voice coil L:0.17 mH
